B&C Electronics PH 7685/E – Rev. B
- 9 -
ANALOG OUTPUT Nr. 1 Default
* Input: pH/mV/°C (option 091.3711) pH
* Range: 0-20/4-20 mA 0-20 mA
* Point 1 (corresponding minimum mAmps):
pH: 0.00/14.00 pH 0.00 pH
Rx: -1000/1000 mV -1000mV
°C: -10.0/110.0°C (option 091.3711) -10.0°C
* Point 2 (corresponding to max. mAmps):
pH: 0.00/14.00 pH 14.00 pH
Rx: -1000/1000 mV 1000mV
°C: -10.0/110.0°C (option 091.3711) 110.0°C
Response time: 2.5 sec for 98%
Isolation: 250 Vca
R max: 600 ohm
ANALOG OUTPUT Nr. 2 (option 091.3711) Default
* Input: pH/mV/°C mV
* Range: 0-20/4-20 mA 0-20 mA
* Point 1 (corresponding to min. mAmps):
pH: 0.00/14.00 pH 0.00 pH
Rx: -1000/1000 mV -1000mV
°C: -10.0/110.0°C -10.0°C
* Point 2 (corresponding max. mAmps):
pH: 0.00/14.00 pH 14.00 pH
Rx: -1000/1000 mV 1000mV
°C: -10.0/110.0°C 110.0°C
Response time: 2.5 sec per il 98%
Isolation: 250 Vca
R max: 600 ohm
RS232 OUTPUT (option 091.701) Default
