main panel – Power Link
Connection procedure:



 




 

    
   




 
        

 

       

   
30
1.
Determine the number of the
socket where the equipment is
connected.
2.
Go to the main panel and  nd
the appropriate patch port.
3.
Patch from Power Link module to
patch port.
4.
Go back to the wall socket and
attach the Power Link symbol.
5.
Connect the cable from the wall
socket to the product. Remember
to set the Left/Right button on
the loudspeakers.
