MASTER LINK
33
Receiver cable
1
5
4
3
2
1
=
Yellow
2
=
Grey
3
=
Green
4
=
White
5
=
Brown
NB:
All Bang & Olufsen products in the
system must be disconnected from
the power source during
installation!
Power Link cable
Ø2.5mm
MKIII
MKIII
Shields from
wires without
insulation
Seen from solderside
Green 5
Brown 3
Ye
llow 4
Blue 7
2
6
1
4
2
5
3
7
8
