8
INSTALLATION
The next steps vary based on whether your pool has one skimmer, two skimmers or a
wall vacuum fitting. Please follow the appropriate instructions for your type of pool.
(2) 45° installation
adapter elbows
(1) FlowKeeper
™
Valve
(1) 4
1
/
2
" Connector
(1) Universal
Valve Cuff
FOR POOLS WITH TWO SKIMMERS
No FlowKeeper
™
Valve required
FOR POOLS WITH WALL VACUUM FITTINGS
No FlowKeeper
™
Valve required
Insert the male end of the hose
into the universal valve cuff.
Insert the male end of the hose into the large end
of one 45° elbow. Then insert the small end of
the 45° elbow into the universal valve cuff. The
45° elbow should be angled toward the surface.
FOR POOLS WITH ONE SKIMMER
❑ Turn the filtration system off.
❑ Using the parts shown below, choose the fitting combination
best suited for your skimmer. You may have parts leftover.
DO NOT INSTALL IN THE SKIMMER AT THIS TIME.
(1) Hose protector
To Next Page
