14
ECO 550
ECO 650
ECO 750
SAVANNAH ATLANTA
2.5.2 Placing soapstone panels ECO 550 / ECO 650 / ECO 750
Position the bottom stone, with the widest part underneath, on the floor.
Position the appliance on top. Secure the side stones by gently sliding them
downwards over the rail. If necessary the rail can be adjusted. Position the top
stone (with the round hole) with the widest part facing upwards.
If you are using the
rear chimney connection, the opening in the top panel needs
to be covered with a special matt-effect stainless steel grill, which is available free
of charge from the dealer
Figure 4: Placing soapstone panels
