barbas ATLANTA - Replacement Parts List

26
ECO 550
ECO 650
ECO 750
SAVANNAH ATLANTA
8 REPLACEMENT PARTS LIST
When requesting service or ordering replacement parts, please quote the model
type and serial number. All parts listed in this manual may be ordered from a
Barbas dealer.
8.1 ATLANTA / SAVANNAH / ECO 550 / ECO 650 / ECO 750
No. Part no. Description
1 302056 Gas regulator block, EuroSIT Plus 0.630.704
2 301965 Piezo push-button
3 302037 Minimal heatinput adj. screw 1,6 mm; Natural gas
4 301967 Minimal heatinput adj. screw 1,3 mm; Propane
5 301969 Pilot light nut + olive; Ø4 mm
6 307524 - 4xØ8,5 Main burner Natural gas G20
7 307493 - 4xØ8,5 + 4xØ6,5 Main burner Propane G31
8 301935 Main burner injector Natural gas; no. 320
9 301933 Main burner injector Propane; no. 170
10 302059 Pilot light set outer casing; SIT 0.160.022
11 301207 Pilot light pipe; Ø4 mm. l= 230 mm
12 301976 Pilot light olive; Ø4 mm
13 301977 Pilot light nut; Ø4 mm
14 302069 Pilot light electrode + cable; l= 250 mm
15 302060 Pilot light injector, Natural gas; no. 41
16 301921 Pilot light injector, Propane; no. 30
17 301971 Thermocouple M10 - 400 mm
18 301970 Thermocouple interrupter M 10
19 301896 Security system T.T.B. 140°C
20 301438 Glass Atlanta-Savannah;centre 311,5 x 340 x 4 mm
21 301439 Glass Atlanta-Savannah; L/R 113,5 x 340 x 4 mm
22 301403 Glass ECO 550, 387 x 412 x 4 mm (R=295 mm)
23 301442 Glass ECO 650, 360 x 425 x 4 mm
24 301458 Glass ECO 750, centre 255 x 415 x 4 mm
25 301459 Glass ECO 750, L / R 90 x 415 x 4 mm
26 301597 Fibre glass tape black (ladder) 25x3 mm
27 301613 Fibre glass tape black 10x2 mm adhesive
28 301617 Fibre glass cord black Ø10 mm
29 301614 Fibre glass tape black 10x2 mm
30 312469 Fibre glass tape black 10x3 mm
