barbas ATLANTA - Technical Details;Regulations

25
ENGLISH
ATLANTA SAVANNAH
ECO 550
ECO 650
ECO 750
7 TECHNICAL DETAILS / REGULATIONS
7.1 TECHNICAL DETAILS;
NG; NATURAL GAS - GREAT BRITAIN / IRELAND PG; PROPANE GAS - GREAT BRITAIN / IRELAND
NI ; NATURAL GAS - ITALIA PI ; PROPANE GAS - ITALIA
NE; NATURAL GAS - ESPAÑA PE; PROPANE GAS- ESPAÑA
NP; NATURAL GAS - PORTUGAL PP; PROPANE GAS - PORTUGAL
National Installatie Regulations: Gas safety installation and use regulations 1984 plus all
relevant safety and building regulations concerning fire
installations
Model : ATLANTA NG/NI/NE/NP : ATLANTA PG/PI/PE/PN
SAVANNAH NG/NI/NE/NP SAVANNAH PG/PI/PE/PN
ECO 550 NG/NI/NE/NP ECO 550 PG/PI/PE/PN
ECO 650 NG/NI/NE/NP ECO 650 PG/PI/PE/PN
ECO 750 NG/NI/NE/NP ECO 750 PG/PI/PE/PN
Country : GB; Great Britain / IE; Ireland / IT; Italia / ES; España / PT; Portugal
Product identification nr. : 0063 AR 3329 : 0063 AR 3329
Type of appliance under CE-norm : B
11BS
: B
11BS
Category of appliance : I
2H
, Natural gas G20 : I
3P
, Propane G31
Nominal heat input (nett calorific value) : 10,3 kW : 9,5 kW
Nominal heat output (max.) : 5,8 - 6,7 kW : 5,2 - 6,2 kW
Gas rate (max.) : 1,09 m
3
s
/hr. : 730 gr/hr.
Supply pressure : 20,0 mbar : 37,0 mbar
Burner pressure (max.) Hot : 9,3 mbar(*) : 29,0 mbar
Burner pressure (max.) Cold : 8,5 mbar(**) : 29,0 mbar
Burner pressure (min.) : 2,0 mbar : 5,0 mbar
Gas regulator block : SIT 0.630.704 : SIT 0.630.704
Min. heatinput adj. screw:
- Thermostatic burner : nr. 160 (= Ø1,60 mm) : nr. 130 (=Ø1,30mm)
- Manual burner : standard : standard
Main burner : Barbas 270 x 122 : Barbas 270 x 122
Primary air inlet main burner : 4x Ø8,5 mm : 4x Ø8,5 mm +
4x Ø6,5 mm
Main burner orifice : nr. 320 : nr. 170
(= 1x Ø3,20 mm) (= 1x Ø1,70 mm.
Pilot burner : SIT 0.160.022 : SIT 0.160.022
Pilot burner orifice : nr. 41 : nr. 30
Security system (T.T.B.) : Thermodisc type: : Thermodisc type:
44T21-316190 -140°C 44T21-316190 -140°C
Gas connection : 3/8" G / Ø12 mm - Ø15 mm : 3/8" G / Ø12 mm - Ø15 mm
Required air supply : 65 cm
2
/ 10 in.
2
: 65 cm
2
/ 10 in.
2
Chimney connection:
- ATLANTA / SAVANNAH : Ø100 mm : Ø100 mm
- ECO 550 / ECO 650 / ECO 750 : Ø150 mm : Ø150 mm
(*) : When the appliance has reached its thermal equilibrium.
(**) : Burner at maximum. Appliance is cold.
Heat-exchanging surface: Entire front of the appliance, exept the control panel.
