4. OPERATION OF THE FITTED FIREPLACE
1 Smoke outlet 7 Convection air-supply slide
2 Convection air escape opening 8 Wood rack
3 Ceramic heat-proof glass 9 Ridling grill handle
4 Handle 10 Primary air-supply slide
5 Secondary air-supply slide 11 Temperature switch holder
6 Ash drawer 12 Cast-iron • ns/inner lining
Figure 1: Operation
