C. ASSEMBLY INSTRUCTIONS
STEP 1 ATTACH MOLDED RUBBER FEET
— Attach the 4x rubber feet to the bottom of the oven body using 4 x M4x20mm screws as
shown below.

STEP 2 ATTACH SMOKE CHIMNEY
— Attach the smoke chimney (1) to the ring on the top of the oven body (2) using 3 x M5x12mm
screws as shown below.


1
