Page 17
Assembly instructions (continued)
STEP 9 CART MODELS ONLY: If the folding feature is not required,
the shelf can be bolted firmly in
place.
WHAT YOU NEED
2 x M6*12mm Locking nuts and bolts
for each shelf.
If folding is not required, lock the shelves into place with 1 x nut and bolt front and back as
below.
If you have two side shelves, attach the second side shelf in the
same way as the first, on the other side of the barbeque. Then
proceed direct to STEP 13.
If you have purchased a side burner, proceed with STEP 10 as
below.
