Page 23
Assembly instructions (continued)
STEP 14 CART MODELS ONLY: Attach the grease channelling tray
handle.
WHAT YOU NEED
2 x M4*10mm screws
1 x Grease Channelling Tray Handle
STEP 15 ALL MODELS: Locate the grease channelling tray into position
Slide the grease channelling tray into the support brackets on the separator panel, so that it is
under the bbq, all the way back. If you have a cart, you need to open the doors to remove the
grease channelling tray. Only when the bbq is cold, remove the grease channelling tray when
required for cleaning and to access the grease cup.
