Assembly instructions (continued)
STEP 21 DELUXE 4B MODELS ONLY: Attach the Ignition Box
WHAT YOU NEED
1 x Electronic Ignitor
1 x Ignitor Cover Box
1 x Battery
a) Remove the cap and nylon locking nut from the Electric Ignitor, put the Ignitor into
the Cover box and lock in place with the nylon locking nut.
b) Fit the wires through the hole into the ignitor box and connect the terminals to the ignitor as
shown.
c) Open the cap of ignitor and put the battery in as shown.
To Next Page
