Barbeques Galore G4CBL - Page 16

Page 16
Assembly instructions (continued)
STEP 7 CART MODELS ONLY: Attach the folding side shelf brackets
WHAT YOU NEED
4 x M6*40 mm long screws
.
STEP 8 CART MODELS ONLY: Attach the side shelf
Screw the side table bracket set to the left side of the bbq
using 4 pieces M6*40mm long screws and the two screws
already pre-fitted to the bracket set.
With the side shelf vertical,
hook it into place.
Tilt the shelf upwards and lock
it into its horizontal position
Push the edges down
to lock the shelf firmly
