Bard MEGA-TEC W090A - Page 127

Manual 2110-1451D
Page 9 of 28
FAN SYSTEM COMPONENTS
W090A*B W120A*B W150A*B W090A*C W120A*C W150A*C W090A*E W120A*E W150A*E W090A*V W120A*V W150A*V W090A*Q W120A*Q W150A*Q
Dwg
No. Part Number Description
1
1
S5155-001-001
S5155-002-001
Fan & Motor Assembly
Fan & Motor Assembly
X X X
X X X
X X X
X X X X X X
2 113-737 Fan Hinge Bracket 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
3 5401-008 Anti-Pivot Rod X X X X X X X X X X X X X X X
4 113X729 RH Gauge Port Bracket X X X X X X X X X X X X X X X
5 113-735 Wheel Retention Rail 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
6 1171-035 Plastic Wheel, 3" Diameter 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
7 1012-353 Cotter Pin 6 6 6 6 6 6 6 6 6 6 6 6 6 6 6
8 8200-056 Fan Slide Welded Frame X X X X X X X X X X X X X X X
9 5451-029 Nylon Sleeve 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
10 5401-007 Fan Stop Rod X X X X X X X X X X X X X X X
11 113-752 Fan Safety Lock Bracket X X X X X X X X X X X X X X X
12 113Y729 LH Gauge Port Bracket X X X X X X X X X X X X X X X
NS 113-738 Wheel Guide Angle 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
NS 113-736 Fan Attachment Angle 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
NS – Not Shown
