FIGURE 55
MEGA-TEC Wall-Mount Unit Model Nomenclature
W 120 A P B 0Z E P X X X X
MODEL SERIES
NOMINAL TOTAL CAPACITY
090 – 7.5 Ton 3 Stage Capacity
120 – 10 Ton 3 Stage Capacity
150 – 12.5 Ton 3 Stage Capacity
CONTROL LOGIC AND CLIMATE OPTIONS
P – Programmable Logic Board
E – Electric Reheat Dehumidification
REVISION
A – Revision Level
VOLTS & PHASE
E – 240/220-50-3
Q – 575-60-3
V – 415/380-50-3
KW
0Z – O kW with Circuit Breaker
09 – 9 kW with Circuit Breaker
18 – 18 kW with Circuit Breaker
VENT
B – No Vent
E – Economizer (DB and WB)
FILTER
M – MERV11 Disposable
P – MERV8 2" Pleated
N – MERV13 2" Pleated
B – 230/208-60-3
C – 460-60-3
COLOR
X – Beige Baked Enamel Finish
1 – White Baked Enamel Finish
4 – Gray Baked Enamel Finish
COIL AND UNIT COATING OPTIONS
X – Standard
1 – Coated Evaporator
2 – Coated Condenser
3 – Coated Evaporator and Condenser
OUTLET
X – Standard
PACKAGING OPTIONS
X – None, Standard Wood Skid
1 – White Steel Skid/Platform
2 – Wood Skid with Crate
3 – White Steel Skid/Platform with Wood Crate
