Manual 2110-1451D
Page 27 of 28
Dwg. No. Part Number Description
1 8602-040 BKP-24 Butterfly Pivot 4
2 539-395 Exhaust Damper Blade X
NS 113-747 Exhaust Damper Blade Stiffening Angle 2
3 113-731 Hinge Bracket X
4 8406-150 Blade Switch X
5 113-743 Blade Switch Bracket X
6 1012-201 1/4"-20 Steel Keps Nut 3
7 113-728 Actuator Mounting Bracket 2
8 141-485 Actuator Mounting Plate X
9 8602-093 Actuator 2-10V 88 IN/LB X
10 8602-100 Terminal Strip Cover X
11 1012-174 1/4"-20 x 3-1/4" Bolt 3
12 8602-008 Ball Joint X
13 139-399 Actuator Arm 2
14 8602-097 1/4" x 16-5/8" Rod X
NS 1012-348 1/2" x 3/4" Nylon Flat Washer 2
15 1012-351 1/4"-20 X 1/2" BTNHD Cap Screw 2
16
16
S121-579
S121-581
Condenser Partition
Condenser Partition
X
X
17 141-487 Exhaust Actuator Support X
18 1921-067-2513 25-13/16" Damper Blade Seal
W090A****E W120A****E W150A****E W090A****B W120A****B W150A****B
EXHAUST DAMPER ASSEMBLY
