FIGURE 8
Wall Mounting Instructions
See Figure 3, Unit Dimensions,
for actual dimensions.
I
A
C
1/4"
E + 1.000
B
K
2 x 4's, 2 x 6's &/OR
STRUCTURAL STEEL
OVER FRAME
EXTERIOR FINISH WALL
PLATE OF WALL
ATTACH TO TOP
REQUIRED FOR SOME WALLS.
SECOND MEMBER MAY BEPLATE OF WALL
ATTACH TO BOTTOM
SPACING FOR REST OF WALL.
INTERIOR FINISHED WALL
OVER FRAME
OPENING
SUPPLY DUCT
OPENING
FRAMING MATERIAL
LOCATED TO MATCH STUD
MIS-3948
RETURN DUCT
THIS STRUCTURAL MEMBER
0.250" CLEARANCE
ALL AROUND DUCT
