Manual 2100-705B
Page 16 of 43
FIGURE 12
Rear Communication and Power Wire Entrances (Optional)
MIS-3956
OPTIONAL REAR
POWER ENTRANCE
OPTIONAL REAR
COMMUNICATION ENTRANCE
MIS-3955
HIGH VOLTAGE
POWER WIRE ENTRANCE
COMMUNICATION
WIRE ENTRANCE
FIGURE 11
Side Communication and Power Wire Entrances (Recommended)
Route communication wiring and power
supply wiring in their own separate conduits.
They must not be run together. Use 2-wire,
18 gauge shielded cable with drain for
communication wire.
MIS-3956
Route communication wiring and power supply
wiring in their own separate conduits. They must
not be run together. Use 2-wire, 18 gauge shielded
cable with drain for communication wire.
