Manual 2100-705B
Page 30 of 43
TABLE 3
LC6000-200 Terminal Block Index
TB#
Wire
Mark
Description
1 - 120 VAC Input
2 - 208 VAC Input
3 - 230 VAC Input
4 - Power Input Common
5 - Power Input Ground
6 DI1 Emergency Off Input
7 GND Emergency Off Common
8 DI2 Emergency Vent Input
9 GND Emergency Vent Common
10 DI3 Generator Run Input
11 GND Generator Run Common
12 B2 Zone 1 Indoor Remote Humidity Sensor
13 GND Ground
14 B3 Zone 2 Indoor Remote Humidity Sensor
15 GND Ground
16 B4 Zone 3 Indoor Remote Humidity Sensor
17 GND Ground
18 B6 Zone 1 Indoor Temperature Sensor
19 GND Ground
20 B7 Zone 1 Indoor Remote Temperature Sensor
21 GND Ground
22 VDC+ Power for B2 (Z1 Humidity)
23 VDC+ Power for B3 (Z2 Humidity)
24 VDC+ Power for B4 (Z3 Humidity)
25 VDC+ Power for B10 (Pressure)
26 B8 Zone 2 Indoor Remote Temperature Sensor
27 GND Ground
28 B9 Zone 3 Indoor Remote Temperature Sensor
29 GND Ground
30 B10 Indoor Space Pressure
31 GND Ground
32 NO1 Humidifier 1
33 C1 Common
34 NO2 Humidifier 2
35 C1 Common
36 NO3 Humidifier 3
37 C1 Common
38 NO4 Emergency Off Alarm
TB#
Wire
Mark
Description
39 C2 Common
40 NO5 Emergency Vent Alarm
41 C2 Common
42 NO6 Generator Run Alarm
43 C2 Common
44 NO7 Indoor Humidity Alarm
45 C7 Common
46 NO8 High Indoor Temperature Alarm
47 C8 Common
48 NO9 Low Indoor Temperature Alarm
49 C8 Common
50 NO10 Zone 1 Unit Alarm
51 C8 Common
52 NO11 Zone 2 Unit Alarm
53 C8 Common
54 NO12 Zone 3 Unit Alarm
55 C8 Common
56 FB1R-
RS485 RX- / TX- (Fieldbus 1)
UNIT CONNECTION
57 FB1R+
RS485 RX+ / TX- (Fieldbus 1)
UNIT CONNECTION
58 FB2R- RS485 RX- / TX- (Fieldbus 2)
59 FB2R+ RS485 RX+ / TX- (Fieldbus 2)
60
-- Power Input Ground
61
24 VAC+ 24 VAC Supply
62
-- Not Used
63
24 VAC+ 24 VAC Supply
64
24 VAC- 24 VAC Ground
65
24 VAC+ 24 VAC Supply for Outdoor Humidity Sensor
66
24 VAC- 24 VAC Ground for Outdoor Humidity Sensor
67 B11 Signal for Outdoor Humidity Sensor
68
24 VAC+ 24 VAC Supply
69 D14 Bard Guard Alarm Signal
70 B12 Signal for Outdoor Temperature Sensor
71 GND Ground for Outdoor Temperature Sensor
72 GND Ground for Bard Guard Alarm Signal
73 G Orange Power Connector
74
24 VAC+ 24 VAC Supply
75 G0 Orange Power Connector
76
24 VAC- 24 VAC Ground
