Bard W42AC-A - Page 84

Manual 2110-1452G
Page 3 of 17
Dwg
No. Part Number Description
1
1
S127-574
S127-584 
Unit Base
Unit Base
X
O
X
O
X
O
X
O
2
2
113-762
113-797 
Front Base Bracket
Front Base Bracket
X
O
X
O
X
O
X
O
3 113-140 Bottom Mounting Bracket X X X X
4
4
4
119-125-* 
119-148 k
119-135 
Front Grille
Front Grille
Front Grille
X
O
O
X
O
O
X
O
O
X
O
O
5
5
5
S533-301-* 
S533-309 k
S533-310 
Control Panel Cover (Outer)
Control Panel Cover (Outer)
Control Panel Cover (Outer)
X
O
O
X
O
O
X
O
O
X
O
O
6
6
6
S165-608-* 
S165-609 k
S165-610 
Rain Channel
Rain Channel
Rain Channel
X
O
O
X
O
O
X
O
O
X
O
O
7
7
7
S515-323-* 
S515-328 k
S515-330 
Upper Front
Upper Front
Upper Front
X
O
O
X
O
O
X
O
O
X
O
O
8
8
8
153-717-* 
153-723 k
153-724 
Disconnect Access Door
Disconnect Access Door
Disconnect Access Door
X
O
O
X
O
O
X
O
O
X
O
O
9
9
9
S501-1027-* 
S501-1028 k
S501-1029 
Right Side
Right Side
Right Side
X
O
O
X
O
O
X
O
O
X
O
O
10
10
10
501-1054-* 
501-1073 k
501-1077 
Left Side
Left Side
Left Side
X
O
O
X
O
O
X
O
O
X
O
O
11 105X1454 Right Support Angle X X X X
12 105Y1454 Left Support Angle X X X X
13 105-1457 Coil Support 2 2 2 2
14 147-055 Coil Support Offset X X X X
15
15
15
119-126-* 
119-142 k
119-136 
Side Grille
Side Grille
Side Grille
2
2
2
2
2
2
2
2
2
2
2
2
16 105-1450 Right Control Panel Angle X X X X
17 105-1451 Left Control Panel Angle X X X X
18
18
18
S543-221-* 
S543-228 k
S543-229 
Heater Access Cover
Heater Access Cover
Heater Access Cover
X
O
O
X
O
O
X
O
O
X
O
O
19
19
19
507-382-* 
507-391 k
507-392 
Top
Top
Top
X
O
O
X
O
O
X
O
O
X
O
O
20
20
20
109-412
109-418 k
109-422 
Lower Back
Lower Back
Lower Back
X
O
O
X
O
O
X
O
O
X
O
O
21
21
21
S509-411
S509-417 k
S509-421 
Upper Back
Upper Back
Upper Back
X
O
O
X
O
O
X
O
O
X
O
O
22 S111-299 Outlet Air Frame Assembly X X X X
23 535-129 Heat Shield X X X X
24
24
24
113-150-* 
113-150-4 k
113-359 
Top Rain Flashing
Top Rain Flashing
Top Rain Flashing
X
O
O
X
O
O
X
O
O
X
O
O
25
25
539-406
543-222
Fresh Air Damper Assembly
Intake Blank Off Plate
X
O
X
O
X
O
X
O
26 543-220 Exhaust Blank Off Plate X X X X
27
27
27
S543-248-* 
S543-250 k
S543-251 
Access Cover
Access Cover
Access Cover
X
O
O
X
O
O
X
O
O
X
O
O
NS 5252-033 Bard Nameplate X X X X
X – Standard Component
O – Optional Component
EXTERNAL PARTS – STANDARD & DEHUMIDIFICATION
W42AC-A, B, C, E, F, RC W42ACDA, B, C W48AC-A, B, C, E, F, RC W48ACDA, B, C
 Exterior cabinet parts are manufactured with various paint color options. To ensure
the proper paint color is received, include the complete model and serial number
of the unit for which cabinet parts are being ordered.
k
Exterior cabinet parts are manufactured from aluminum Code "A". #24 - Top rain
ashing not available in aluminum; order 113-150-4 (Buckeye Gray).

Exterior cabinet parts are manufactured from stainless steel Code "S"
