Bard W42AC-A - Page 88

Manual 2110-1452G
Page 7 of 17
Dwg
No. Part Number Description
1
1
125-089
125-093 
Fan Shroud
Fan Shroud
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
2
2
S125-090
S125-094 
Fan Shroud Side Access Cover
Fan Shroud Side Access Cover
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
3
3
121-586
121-600 
Condenser Partition Insert
Condenser Partition Insert
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
4
4
121-585
121-599 
Condenser Partition
Condenser Partition
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
5 521-630 Front Exhaust Partition X X X X X X X X
6 521-587 Exhaust Partition X X X X X X X X
7 Control Panel Assy. See Control Panel Assy. Drawing & Parts List X X X X X X X X
8 S133-330 Control Panel Cover (Inner) X
X X X X X X X
9 105-1453 Front Vent Guide Rail X X X X X X X X
10 105-1452 Vent Guide Rail X X X X X X X X
11 S135-409 Field Wire Shield X X X X X X X X
12 131-168 Filter Support Bracket 2 2 2 2 2 2 2 2
13 131-170 Filter Slide X X X X X X X X
14 131-169 Filter Rack Frame X X X X X X X X
15 121-583 Filter Partition X X X X X X X X
16 117-412 Upper Control Panel X X X X X X X X
17
17
127-575
127-585
Circuit Breaker Base
Circuit Breaker Base - 460V
X
X
X
X
X
X
X
X
18
18
S133-303
S133-304
Upper Control Panel Cover
Upper Control Panel Cover - 460V
X
X
X
X
X
X
X
X
19
19
135X393
135X397 
Right Copper Chase
Right Copper Chase
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
20
20
135Y393
135Y397 
Left Copper Chase
Left Copper Chase
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
21 113-796 Copper Retainer 2 2 2 2 2 2 2 2
22 137-920 Copper Fill Plate 2 2 2 2 2 2 2 2
25 113-765 Grommet Retainer X X X X X X X X
26 141-492 Blower Partition Support X X X X X X X X
27 121-582 Blower Partition X X X X X X X X
28
28
523-161
523-162 k
Drain Pan
Drain Pan
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
29 113-768 EEV mounting Bracket X X X X
30 113-787 Airow Switch Bracket O O O O O O O O
31 113-788 Filter Switch Bracket
O O O O O O O O
32 113-789 Filter Switch Light Bracket O O O O O O O O
X – Standard Component
O – Optional Component
INTERNAL PARTS – STANDARD & DEHUMIDIFICATION
W42AC-A, B, E W42AC-C, F, RC W42ACDA, B W42ACDC W48AC-A, B, E W48AC-C, F, RC W48ACDA, B W48ACDC
 Exterior cabinet parts are manufactured from stainless steel Code "S"
k For aluminum units, order 523-162 stainless steel drain pan.
