Bard W42AC-A - Page 98

Manual 2110-1452G
Page 17 of 17
Dwg No. Part Number Description
1 5152-011 10 Inch Wheel (CW) X X X X X X X X
2 5152-012 10 Inch Wheel (CW) X X X X X X X X
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
3
S8106-068-0155
S8106-069-0156
S8107-028-0157
S8107-028-0159
S8107-028-0161
S8107-029-0158
S8107-029-0160
S8107-029-0162
C8106-068-0155
C8106-069-0156
C8107-028-0157
C8107-028-0159
C8107-028-0161
C8107-029-0158
C8107-029-0160
C8107-029-0162
Programmed Blower Motor & Control (230/208V)
Programmed Blower Motor & Control (460V)
Programmed Blower Motor & Control (230/208V)
Programmed Blower Motor & Control (230/208V)
Programmed Blower Motor & Control (230/208V)
Programmed Blower Motor & Control (460V)
Programmed Blower Motor & Control (460V)
Programmed Blower Motor & Control (460V)
Programmed Control Only (230/208V)
Programmed Control Only (460V)
Programmed Control Only (230/208V)
Programmed Control Only (230/208V)
Programmed Control Only (230/208V)
Programmed Control Only (460V)
Programmed Control Only (460V)
Programmed Control Only (460V)
X
O
X
O
X
O
X
O
X
O
X
O
X
O
X
O
4 8200-040 Motor Mount X X X X X X X X
5 5451-011 Grommets 6 6 6 6 6 6 6 6
6 112-775 Motor Control Bracket X X X X X X X X
7 105-880 Side Angle 4 4 4 4 4 4 4 4
8
105-881 Back Brace X X X X X X X X
9 103-541 Front Mounting Offset X X X X X X X X
10 144-166 Diffuser 2 2 2 2 2 2 2 2
11 151-101 Blower Housing 2 2 2 2 2 2 2 2
BLOWER ASSEMBLY
8
9
2
7
7
7
1
SEXP-929
10
10
3
4
5
11
11
7
3
6
S900-366-001 S900-367-001 S900-368-001 S900-368-002 S900-368-003 S900-369-001 S900-369-002 S900-369-003
