Bardiani ZQ - Part List

(GB-IST-ZQ-0413) 34/36
The Company BARDIANI VALVOLE reserves the right to modify its products at any time without prior notice.
17. Part list
Item Description Item Description
1 Lower body 85 Spring
2 Shutter 88 Grub screw
4 Seal ring 99 Cylinder
6 Seal ring 101 Screw
7 Washer 102 Screw
8 Screw 108 Seal ring
9 Cylinder 110 Screw
10 Guide bushing 120 Guide bushing
11 Pivot 129 Pivot
12 Seal ring 154 Thickness
13 Piston 156 Seal ring
14 Seal ring 157 Seal ring
16 Seal ring 168 Guide bushing
17 Guide bushing 169 Seal ring
18 Stopper cylinder 170 Screw
19 Seal ring 171 Seal ring
20 Snap ring 172 Seal ring
23 Upper pivot 173 Stopper cylinder
24 Airtting 174 Seal ring
28 Shutter nut 175 Guide bushing
30 Double shutter 176 Seal ring
35 Assembly 177 Snap ring
40 Plug 204 Guide bushing
42 Upper body 205 Guide bushing
45 Steam barrier 225 Seal ring
47 Seal ring 226 Seal ring
50 Cap
55 Seal ring
57 Seal ring
59 Screw
66 Piston
