barebones STR-556 - Step 3: ASSEMBLE 2 CROSS BEAMS

STEP 3 : ASSEMBLE 2 CROSS BEAMS
Pole E
Pole B
1) Attach the (E) pole to the (B) pole.
2) Attach swivel joints to the ends and secure the popple.
3) Attach cross bar assembly to each roof end as shown below. Open the swivel joint clamp,
attach to poles and secure with bolt and wing nut.
(B) Pole
(E) Pole
(I) Swivel joint
Parts Needed :
