barfield DC400A - 7. System Wiring Integrity Test

61-101-00802.EF1 Revision J Page | 23
Aircraft
Tank Unit
Beech Probe P/N
Min.
Nom.
Max.
A100, B100,
200, 250,
300 / 350i,
360, E90
Aircraft with 100-380006-59 Harness
Bulkhead Cable Assy.
100-380006-59
16.8
21.8
26.8
Cable Assy & Integral
Tank Units
100-380006-15, -17,
-59
41.5
46.5
51.5
Aircraft with 100-380006-99, -127 Harness
Cable Assy & Integral
Tank Units Combined
100-380006-93, -95,
-121, -123, -179, -181
37.8
42.1
46.3
Table 8 Probe Capacitance Empty (pF)
Note: The probes and harnesses in Table 8 were installed in aircraft with S/N LW17,
LW69 through LW214, B152, B156 through B234, BE1 through BE24 and BB2
through BB220.
Note: The -59 harness has diodes mounted in it and can be tested without any probes
attached.
The -15 and -17 probe cannot be tested without the –59 harness attached.
Note: Refer to Beech Service Bulletin, 0648-355, for replacement P/N’s of the 100-
380006-15, 17, & 59 cables and probes.
Aircraft C90, C90A / B / GT / GTi / GTx & C99
Tank Unit
Beech Probe P/N
Min.
Nom.
Max.
Leading Edge Inboard
100-380006-11, -69, -105, -139, -143, -175
40.3
44.8
49.3
Leading Edge Outboard
100-380006-13, -67, -103, -187
34.3
38.1
41.9
Inboard Aft
100-380006-37, -71, -107, -141, -145, -173
24.5
27.2
29.9
Center Section
100-380006-7, -73, -109, -183
46.2
51.3
56.4
Nacelle (C90 / C90A / B /
GT / GTi / GTx)
100-380006-49, -79, -97, -125, -185
79.3
88.1
96.9
Nacelle (C99)
100-380006-77, -113, -171
74.1
82.3
90.5
Table 9 Probe Capacitance Full (pF)
Aircraft A100, B100, E90 & F90
Tank Unit
Beech Probe P/N
Min.
Nom.
Max.
Leading Edge Inboard
100-380006-11, -69, -105, -139, -143, -175
40.3
44.8
49.3
Leading Edge Outboard
100-380006-13, -67, -103, -187
34.3
38.1
41.9
Inboard Aft
100-380006-37, -71, -107, -141, -145, -173
24.5
27.2
29.9
Integral Inboard
100-380006-93, -121, -179
31.1
34.6
38.1
Integral Outboard
100-380006-95, -123, -181
26.5
29.4
32.3
Auxiliary
100-380006-7, -73, -109, -183
46.2
51.3
56.4
Nacelle (E90)
100-380006-43, -75, -111, -189
79.3
88.1
96.9
Nacelle (A100, B100,
F90)
100-380006-41, -77, -113, -171
74.1
82.3
90.5
Table 10 Probe Capacitance Full (pF)
