Barnstead FB1300 - Replacement Parts List

27
Quantity
Key# Description Required Part Number
1 Heating element (100V - FB1314M) 1 EL140X2
1 Heating element (120V - FB1315M) 1 EL44X1
1 Heating element (208V - FB1318M) 1 EL44X3
1 Heating element (240V - FB1310M, -33) 1 EL44X2
1 Heating element (100V - FB1414M) 1 EL186X2
1 Heating element (120V - FB1415M) 1 EL48X1
1 Heating element (208V - FB1418M) 1 EL48X3
1 Heating element (208V - FB1410M, -33) 1 EL48X2
2 Thermocouple (FB1300 all models) 1 TC745X1A
2 Thermocouple (FB1400 all models) 1 TC746X1A
3 Solid State Relay (FB1300, FB1400 all models) 1 RYX54
4 Door Switches (all models) 2 SWX163
5 PC Board (FB1315M, FB1415M) 1 PC745X1A
5 PC Board (FB1310M, -26, FB140M, -26) 1 PC745X2A
5 PC Board (FB1314M, FB1414M) 1 PC745X3A
5 PC Board (FB1318M, FB1418M) 1 PC745X4A
6 Insulation Btm (all FB1300 models) 1 JC44X1
6 Insulation Btm (all FB1400 models) 1 JC48X2
7 Insulation Back (all FB1300 models) 1 JC44X4
7 Insulation Back (all FB1400 models) 1 JC48X1
8 Insulation Top (all FB1300) 1 JC44X3
8 Insulation Top (all FB1400) 1 JC48X3
9 Insulation Hearth Collar (FB1300) 1 HC44X1
9 Insulation Hearth Collar (FB1400) 1 HC48X1
10 Insulation Sides (FB1300) 2 JC460X2
10 Insulation Sides (FB1400) 2 JC48X4
11 Cycle Light (amber) (all 100V & 120V) 1 PLX103
11 Cycle Light (amber) (all 208V & 240V) 1 PLX104
12 Push To Set button 1 SW745X1A
13 Temperature setpoint adjustment (all models) 1 RS745X1A
14 Power Switch (FB1300 100 & 120V models) 1 SWX137
14 Power Switch (FB100 208 & 240V models) 1 SWX138
14 Power Switch (FB1400 100 & 120V models) 1 SWX143
14 Power Switch (FB1400 208 & 240V models) 1 SWX144
15 Door Assembly (FB1300 all models) 1 DR347X1A
15 Door Assembly (FB1400 all models) 1 DR348X1A
16 Element Sleeving (all models) 1 SL745X1
17 Element Sleeving (all FB1300 models) 1 SL59X2
17 Element Sleeving (all FB1400 models) 1 SL745X1
18 Hearth Plate (all FB1300 models) 1 PH44X1
18 Hearth Plate (all FB1400 models) 1 PH48X1
19 Filter (all -33 models) 1 CAX98
20 Fuse Holder (all -33 models) 1 FZX26
21 Fuse 10 amp .25 + 1.25 - (Buss™ Type ABC, 2 FZX30
all -33 models)
Replacement Parts List
