Principal Tightening Torques
Tightening Torque by Model
GM2810A
Tighten the following bolts and nuts at the torque specified in the table.
For thread locking adhesive, apply a middle strength thread locker (ThreeBond 1322 or equivalent
anaerobic sealant).
Location Code Part name
Tightening torque
Thread locking
adhesive
N-m kgf-cm lb-in
Front wheel
Motor housing K0014160402
Bolt, heat-treated
M16-40P1.5
152 -
188
1549.94 -
1917.04
1345.35 -
1663.99
－
Motor K0013140502 Bolt, heat-treated M14-50 100 1019.7 885.1 －
Wheel
mounting
base
1 1/4-18UNF
Slotted nut (Hydraulic
motor)
400 -
430
4078.80 -
4384.71
3540.40 -
3805.93
－
Disc brake K001A080401
Bolt, w/hexagon hole,
M8-40
28 - 38
285.52 -
387.49
247.83 -
336.34
－
Wheel K0014120652
Bolt, heat-treated
M12-65P1.5
110 1121.69 973.61 －
Rear wheel
Wheel
mounting
base
K0138240002 24 slotted nut high P1.5
180 -
200
1835.46 -
2039.40
1593.18 -
1770.20
－
Wheel K0014120652
Bolt, heat-treated
M12-65P1.5
110 1121.69 973.61 －
Front axle K0015200702
Bolt, heat-treated
M20-70P1.5
370 -
450
3772.89 -
4588.65
3274.87 -
3982.95
－
Brake ass'y
K1720000260
K1720000270
M12 nut (accessories) 50 - 70
509.85 -
713.79
442.55 -
619.57
○
Engine
K0012120352
Bolt, heat-treated
M12-35P1.25
67 - 85
683.20 -
866.75
593.02 -
752.34
－
K0015120552
Bolt, heat-treated
M12-55P1.25
67 - 85
683.20 -
866.75
593.02 -
752.34
－
K0011100502
Bolt, heat-treated
M10-50P1.25
58 - 76
591.43 -
774.97
513.36 -
672.68
－
K0013121102
Bolt, heat-treated
M12-110
67 - 85
683.20 -
866.75
593.02 -
752.34
－
K3680000030
M3.5 Screw
(accessories)
0.78 -
1.18
7.95 -
12.03
6.90 -
10.44
－
Electric
components for
engine
- Starter B terminal (M8)
5.9 -
11.7
60.16 -
119.30
52.22 -
103.56
－
- Alternator B terminal (M6)
5.9 -
9.8
60.16 -
99.93
52.22 -
86.74
－
-
Glow plug connection
terminal nut (M4)
1.0 -
1.8
10.20 -
18.35
8.85 -
15.93
－
Flywheel adapter
K0011100302
Bolt, heat-treated
M10-30P1.25
58 - 76
591.43 -
774.97
513.36 -
672.68
－
K0010100352 Bolt, heat-treated M10-35 45 - 76
458.87 -
774.97
398.30 -
672.68
－
Appended Table
GM2810A
Appended Table
Page 8-5
Tightening Torques
