Pg. 7
COMPLETE INSTRUCTIONS
ELEVATION AIRINTAKE SETTING
INSTALLING THERMOMETER & CLEAT
Properly setting the air-intake
is the key to getting the cooker
to cook at the optimal temp
and to assure there are no are-
ups. Pull the intake slider out to
reveal the dots that represent
your city's elevation. Use Google
to nd your location's elevation.
1 DOT = 0 - 2,000’
2 DOTS = 2,000 - 5,000’
3 DOTS = 5,000 - 8,000’
4 DOTS = 8,000 - 10,000’
As desired, the elevation setting
can be adjusted to let in more
or less air. When the slider is
completely pulled out (showing
4 rows of dots) the air intake is
fully open.
Bottom view of the
air intake slider.
1. From the top of the lid, insert thermometer through the gasket.
2. From inside barrel attach cleat
(point it to center of lid ) and bolt.
3. Be sure to tighten well,
but do not over tighten.
