825TKL OPERATOR’S MANUAL 2/10/20 Page 11 of 28
ENGINE START UP PROCEDURE
Your 825TKL is setup with an automatic glow plug warmer. If the coolant temperature is below
140F°, the glow plugs will warm for 5-10 seconds.
1. Insert key into ignition
2. Set throttle at low idle
3. Turn key to the first setting (ACC). The glow plugs will warm if necessary
4. Turn key to “START” position to engage starter. Engine should fire within a few seconds. Do
not run the starter more than 20 seconds at a time. This may damage the starter motor.
5. Warm up the engine at a medium idle without load
Check to make sure the oil pressure light goes off. If the oil pressure light remains on, turn engine off
immediately and determine the cause.
ENGINE SHUT DOWN PROCEDURE
1. Return the speed control lever to idle
2. Turn the key off
Allow engine to cool before refueling.
