Barrette DECORATIVE SCREEN PANEL FRAME KIT - Before You Begin

2
Drill
Pencil
Tape Measure
Rubber Mallet
3" Spacer Blocks
Level
TOOLS/MATERIALS NEEDED:
BEFORE YOU BEGIN:
Check your local zoning laws.
• Local zoning laws and Home Owners
Associations may regulate the location, style
and height of your product or even require a
permit signoff beforehand.
• Check local codes for frost line depth and
regulations.
• Additional products and assembly may be
required to meet wind code requirements.
Notice of acceptance (NOA) can be found at
www.miamidade.gov/building/pc-search_app.asp
Contact your local utilities companies.
• You must have the utility companies clearly
mark your property for electrical, gas or
water lines to avoid puncturing any unseen
underground utilities.
•
NOTE:
Installation is best accomplished with two
sets of hands.
WARNING:
• Improper installation of this product can result in personal injury. Always wear safety goggles when
cutting, drilling and assembling the product.
• Incorrect installation may cause harm to the product or individual.
• Check local building codes to determine pool-safe product options.
NOTICE:
• DO NOT attempt to assemble the kit if parts are missing or damaged.
• DO NOT return the product to the store. For assistance or replacement parts call: 1-800-336-2383.
2x4 Frame Kit
Component list:
2x4 Line Extension
Frame Kit
Component list:
2x4 Corner Extension
Frame Kit
Component list:
QTY. Description
2
2" Aluminum Posts
2
Top/Bottom U-Channels (Rails)
2
Mid H-Channels (Rails)
1
Surface Mount Kit
2
Post Caps
1
Hardware (Screw Kit)
1
#2 Square Drive Drill Bit
1
1/8" Pre-Drill Bit
1
#3" Phillips drill bit
QTY. Description
1
2" Aluminum H-Post
2
Top/Bottom U-Channels (Rails)
2
Mid H-Channels (Rails)
1
Surface Mount Kit
1
Post Cap
1
Hardware (Screw Kit)
1
#2 Square Drive Drill Bit
1
1/8" Pre-Drill Bit
1
#3" Phillips drill bit
QTY. Description
1
2" Aluminum Corner Post
2
Top/Bottom U-Channels (Rails)
2
Mid H-Channels (Rails)
1
Surface Mount Kit
1
Post Cap
1
Hardware (Screw Kit)
1
#2 Square Drive Drill Bit
1
1/8" Pre-Drill Bit
1
#3" Phillips drill bit
(3) 2x4 Decorative
Screen Panels
3/8" Bolts/Screws
(For surface mounting)
SOLD SEPARATELY:
To obtain and review a copy of the warranty please visit barretteoutdoorliving.com.
You may also contact us at 1-800-336 2383 or email CS.outdoorliving@ebarrette.com.
