Barrette DECORATIVE SCREEN PANEL FRAME KIT - Finishing Touches and Extensions

5
9.
10.
11.
12.
Repeat steps 7 & 8 for the middle and top panel
(Fig. 8).
NOTE:
Always use a tape measure to verify rails are
equal space from each other and that they
are level.
Place post caps on top of posts (lining up the
tabs underneath to the holes in the post). Using
a rubber mallet, fully seat the cap onto the post
(Fig. 9).
NOTE:
If installing additional frame kits (line or
corner), install these prior to placing post
caps on posts.
To connect additional frame kits, line and corner
extension kits are available.
Assemble trim ring over plate. Take one side
of trim ring and push plugs through holes
underneath. Take second half of the trim ring and
push together (Fig. 10).
Fig. 9
Fig. 8
Fig. 10
