3. Attach Equatorial Mount to the newly built tripod with the screw shown in the
picture below.
4. Attach Counter Weight to Counter Weight Shaft and screw the newly made
Counter Weight to the Equatorial Mount as shown on the left and tighten the
Counter Weight with screw.
5. Attach & tighten Shorter Control Cable to Equatorial Mount shown in picture on
the left and Longer Control Cable to Equatorial Mount shown in picture
the right.
NOTE Should look like picture below on the after you have installed the
counterweight and 2 control cables.
675 Power, 900114 Starwatcher Telescope 675 Power, 900114 Starwatcher Telescope
4 5
