Bartec BCS 3678ex-NI Supplementary Description

BCS36x8
ex
Series Connection example
Type 17-A1S4-*HP* and B7-A2S4-****
Page 50 of 78
Subject to technical changes.
05/2020
Supply module Ex i - terminal assignment
Terminal Mains connection / RS232 interface
X1 L = 100 V
AC
to 240 V
AC
±10% / 50/60 Hz
X2 N = Neutral conductor
X3 24 V
DC
+ ±10% / 0.4A
X4 24 V
DC
– ±10% / 0.4A
X5
TxD
X6
RxD
X7
RTS
X8
CTS
X9
GND
X10
-
Supply module Ex i
Scan the programming code for the RS232 serial interface.
The supply module Ex i is already preset on the hardware side to the wired scanner version.
