ex
4 Product description
Subject to technical modifications
Revision A / 04/2019
35 / 106
4.6.1 Terminal assignment
Terminal assignment for installing power cords and RS 232, RS 422, RS 485 and USB-SPP types of
connection cable on the host PC side:
Terminal
Marking
RS 232
RS 422
RS 485
USB-SPP
X1
L
L = 85 V
AC
bis 250 V
AC
X2
N
N = Neutral conductor
X3
24 V
DC
+
24 V
DC
+
X4
24 V
DC
24 V
DC
X5
TxD; RX
;TXRX; M (D–)
TxD
TxD-
TxD/RxD
M (D–)
X6
RxD; RX+; P
(D+)
RxD
RxD-
P (D+)
X7
RTS; TX-;
TXRX+
RTS
TxD+
TxD/RxD+
X8
CTS; TX+
CTS
RxD+
X9
GND
GND
X10
Shield
-
-
-
-
Table 31 Terminal connection plan
The wire braid of the data cable must be inserted into the shield terminal and the braid must also be
connected to terminal X10.
Connection examples see chapter 7.5 or separate description available on the BARTEC download
page.
- - Additional description - Connection examples for BCS 3600
ex
series
The connection using the 7-pole round plug is configured as follows:
Terminal
Marking
Colour cable version
1
Colour cable version
2
1
+UB
Yellow
Red
2
RxD
Green
Green
3 TxD White White
4
RTS
Brown
Brown
5
CTS
Orange
Orange
6 Grey Grey
7 GND Red / black Black
Table 32 Terminal connection plan for 7-pole round plug
Version 1 and version 2 differ in the color of the seal on the RJ45 connector.
Version 1 black gasket, version 2 green gasket
