4 Product description
Subject to technical modifications
Revision A / 04/2019
39 / 106
Shield clamp
Ferrite core
- For snapping onto the top-hat rail in the
universal supply module.
- Fixes the ferrite core
- Ferrite core for shielding external
interference signals
Installation in a universal supply module
Table 38 Connection of the ferrite core to the USM
