HSB+ trace heater
Self-regulating trace heater for installation on
pipes, tanks etc.
Fluoropolymer outer jacket: suitable for exposure to organic
chemicals
Approved for Zone 1/21 and Zone 2/22 areas.
See data sheet for full details.
120 Vac
15 W/m
30 W/m
45 W/m
60 W/m
230 Vac
15 W/m
30 W/m
45 W/m
60 W/m
Catalog No.:
5HSB+1-CT
10HSB+1-CT
15HSB+1-CT
20HSB+1-CT
Catalog No.:
5HSB+2-CT
10HSB+2-CT
15HSB+2-CT
20HSB+2-CT
Order No.:
400821
400822
400823
400824
Order No.:
400825
400826
400827
400828
Part No.:
07-584B-115F
07-584B-130F
07-584B-145F
07-584B-160F
Part No.:
07-584B-715F
07-584B-730F
07-584B-745F
07-584B-760F
HTSB trace heater
Self-regulating trace heater for installation on
pipes, tanks etc.
Fluoropolymer outer jacket: suitable for exposure to organic
chemicals
Approved for Zone 1/21 and Zone 2/22 areas.
See data sheet for full details.
120 Vac
15 W/m
30 W/m
45 W/m
60 W/m
75 W/m
90 W/m
230 Vac
15 W/m
30 W/m
45 W/m
60 W/m
75 W/m
90 W/m
Catalog No.:
5HTSB1-CT
10HTSB1-CT
15HTSB1-CT
20HTSB1-CT
25HTSB1-CT
30HTSB1-CT
Catalog No.:
5HTSB2-CT
10HTSB2-CT
15HTSB2-CT
20HTSB2-CT
25HTSB2-CT
30HTSB2-CT
Order No.:
400829
400830
400831
400832
400833
400834
Order No.:
400835
400836
400837
400838
400839
400840
Part No.:
07-584C-115F
07-584C-130F
07-584C-145F
07-584C-160F
07-584C-175F
07-584C-190F
Part No.:
07-584C-715F
07-584C-730F
07-584C-745F
07-584C-760F
07-584C-775F
07-584C-790F
Power connection. splice and junction components
PBS-200-E/E10 Single power entry con-
nection kit "on pipe"
For connection of a trace heater inside a junction
box. Includes a mounting stand for on-pipe instal-
lation and a silicone end seal.
Maximum power conductor size:
PBS-200-E 6 mm²
PBS-200-E10 10 mm²
2 pipe straps per stand required.
For a complete list of kit contents and approvals see
data sheet.
PBS-200-E:
Catalog No.: PBS-200-E
Part No.: 27-54P2-42221B10
PBS-200-E10:
Catalog No.: PBS-200-E10
Part No.: 27-54P2-43223B10
PBS-300-E/E10 Single power entry con-
nection kit "off pipe"
For connection of a trace heater inside a
junction box. Includes a mounting stand for
off-pipe installation and a silicone end seal.
Maximum power conductor size:
PBS-300-E 6 mm²
PBS-300-E10 10 mm²
2 pipe straps per stand required.
For a complete list of kit contents and approvals see
data sheet.
PBS-300-E:
Catalog No.: PBS-300-E
Part No.: 27-54P2-42111B10
PBS-300-E10:
Catalog No.: PBS-300-E10
Part No.: 27-54P2-43113B10
