Titan 78, 88, 96:
1. Remove the cover from the pulley system.
2. Remove the U-joint by loosening the set screw near
the shaft.
3. Remove the bearing plate.
4. Locate the threaded hole near the center of the driven
pulley. Insert an M6 bolt to open the pulley.
5. Slip the belt off the driven pulley.
