Bartell B436 - Gearbox Assembly

ITEM
NO.
PART NO. DESCRIPTION QTY. REMARK
201 20820 SPIDER PLATE ASSEMBLY 1 5/1/2004
202 20928 GEARBOX ASSEMBLY 1 4/7/1998
203 20626 PRESSURE PLATE ASSEMBLY 1 1/1/2002
204 10608
KEY, 1/4”SQ x 1-5/32”lg
1
5/1/2002
205 10804
SPIDER PLATE RETAINER
1
1/1/1997
206 10802 SOCKET HEAD SCREW, RETAINER 1 1/1/1997
207 10823
CAP PLUG EC-12
1
1/1/1997
208 10311 YOKE ARM 1 3/1/2004
209 10914 YOKE PIN 1 1/1/1997
210 10913 RETAINING RING, E TYPE 2 1/1/1997
215 10910 STUD, 3/8”-16 x 1-3/4”LG 4 1/1/1997
216 10902 LOCK WASHER, 3/8” DIA, MEDIUM 4 1/1/1997
217 10901
HEX NUT, 3/8”-16
4
1/1/1997
218 15346
MOUNTING RAIL, FRONT
1
4/15/2011
219 15347
MOUNTING RAIL, REAR
1
4/15/2011
220 50001
SHCS, 3/8”-16 x 3/4”LG, BLK OXIDE
4
4/15/2011
221 30142
HHCS, 5/16-18UNC x 3/4
1
4/15/2011
