ITEM
NO.
PART NO.
DESCRIPTION QTY.
REMARK
20611
20611
301 20564 HANDLE BRACKET 1 8/20/2007
302 10505 HANDLE CLAMP 1 8/20/2007
303 21718 HANDLE TUBE 1 1/14/2008
304 21719
SUPPORT BLOCK
1
1/14/2008
305 21705
PULLEY
1
1/14/2008
306 21706
DOWEL PIN
1
1/14/2008
307 13349 FLAT HD. CAP SCREW, M10-1.5 x 70MM 1 8/20/2007
308 14989
HEX HD. CAP SCREW, M10-1.5 x 30MM
4
8/20/2007
309 11802 NYLOCK NUT, M10-1.5 5 8/20/2007
310 21720 HAND KNOB ASSEMBLY W/BEARINGS 1 1/14/2008
310-1 21707 HAND KNOB 1 1/14/2008
310-2 21708 SPRING PIN 1 1/14/2008
310-3 21709 THRUST BEARING 1 1/14/2008
310-4 21731 BUSHING 1 1/14/2008
310-5 21711
WASHER
1
1/14/2008
310-6 21712 RETAINING RING 1 1/14/2008
310-7 21713 SCREW SHAFT 1 1/14/2008
310-8 50266 WAVE WASHER 1 ---
311 21722 SLIDE BUSHING 1 1/14/2008
312 21723 CABLE, PITCH CONTROL 1 1/14/2008
313 21724 SPRING PIN 1 1/14/2008
317 10508 THROTTLE ASSEMBLY, CABLE C/W LEVER 1 8/20/2007
318 10703 LOCK WASHER, #10 DIA, INTERNAL 2 8/20/2007
319 21728 RHMS, M5-0.8 x 8MM 2 1/14/2008
320 11852 SAFETY SWITCH 2 1/14/2008
321 20703 WIRE ASSEMBLY 1 8/20/2007
323 21717 HANDLE GRIP (PAIR) 1 1/14/2008
325 10317 NYLOCK NUT, 3/8”-16UNC 1 8/20/2007
330 21727 WIRE ASSEMBLY, SAFETY, 27” EURO 1 1/14/2008
331 21721 HANDLE SHIELD PAD 1 1/14/2008
PARTS LIST 4
WALK-BEHIND TROWELS
HANDLE ASSEMBLY - 20611 EUROPEAN SPEC.
