Bartell Innovatech Terminator Infinity 2.0 - Component Breakdowns

P a g e | 18
OIPB-I01029-Infinity2.0_v1.2
Front Panels & Seat Breakdown
Item No.
Part Number
Description
Qty.
101
11-0085
Pan Head Phillips Screw, #6-32 x 1/2”
4
102
12-0018-06
Lock Washer, M6
4
103
12-0026
Hex Head Cap Screw, M6-1.0 x 12mm
4
104
12-0043-16
Serrated Flange Cap Screw, M6-1.0 x 16mm
23
105
13-0257
GT50 Seat w/ microswitch
1
106
23-0155
Infinity Flanged Inlet Receptacle
2
107
53-0363
Uni-Frame Assembly
1
108
53-0370
Uni-Frame Front Side Panel
2
109
53-0397
Uni-Frame Seat Mounting Bracket
2
110
53-0418
Infinity Front Panel
1
111
96-0389
Infinity Seat Platform Assembly
1
