Front Exterior Breakdown
Item No.
Part Number
Description
Qty.
201
11-0035
Flat Washer, 3/8”
8
202
11-0045
Adjustable Clevis Pin, 5/8” x 3” L
2
203
11-0052
Hitch Pin
8
204
11-0236
Clevis Pin, 1/2” x 3” L
2
205
12-0021-10
Nyloc Nut, M10-1.5
4
206
12-0034-40
Hex Head Cap Screw, M10-1.5 x 40mm
4
207
13-0378
Caster Wheel Replacement
1
208
31-0043
Hydraulic Fitting, 90 deg 4 JIC – 8 SAE
2
209
34-0015
Hydraulic Ram (90 deg)
1
210
53-0117
Foot Rest, 1-piece
1
211
96-0386
Pivoting Jaw Assembly
1
