P a g e | 20
OIPB-I01029-Infinity2.0_v1.2
Front Interior Breakdown
Item No.
Part Number
Description
Qty.
301
12-0018-06
Lock Washer, M6
2
302
12-0018-08
Lock Washer, M8
8
303
12-0026
Hex Head Cap Screw, M6-1.0 x 12mm
4
304
12-0032-25
Hex Head Cap Screw, M8-1.25 x 25mm
6
305
12-0032-30
Hex Head Cap Screw, M8-1.25 x 30mm
2
306
12-0035-06
Flat Washer, M6
2
307
12-0035-08
Flat Washer, M8
4
308
12-0043-16
Serrated Flange Cap Screw, M6-1.0 x 16mm
6
309
12-0051
Socket Head Cap Screw, M5-0.8 x 16mm
2
310
12-0053
Hex Jam Nut, M10-1.5
5
311
13-0385
Infinity Drive Lever Knob, 1/2"-13, 1 7/8” dia.
2
312
23-0157
Circuit Breaker, 80A 48V
1
313
24-0231
Junction Stud
1
314
35-0059
Infinity Jaw Lever
1
315
53-0427
Infinity Drive Lever
2
316
53-0429
Infinity Charger Bracket
2
317
53-0430
Infinity Charger Mount
1
318
81-0671
Infinity Primary On-board Charger
1
319
96-0384
Infinity Controls Assembly (L)
1
320
96-0385
Infinity Controls Assembly (R)
1
