Bartell Innovatech Terminator Infinity 2.0 - Page 21

P a g e | 21
OIPB-I01029-Infinity2.0_v1.2
Battery Area Breakdown
Item No.
Part Number
Description
Qty.
401
11-0069
Lock Washer, 1/4”
2
402
11-0092
Hex Head Cap Screw, 1/4"-20 x 1/2"
2
403
12-0043-16
Serrated Flange Cap Screw, M6-1.0 x 16mm
6
404
12-0045-20
Flat Head Phillips Screw, M6-1.0 x 20mm
4
405
31-0051
Hydraulic Fitting, 90 deg 12 JIC – 12 SAE
1
406
31-0282
Hydraulic Fitting, Straight 6 JIC – 12 SAE
1
407
31-0283
Hydraulic Fitting, Branch Tee 6 JIC – 12 SAE
1
408
31-0284
Hydraulic Fitting, 90 deg 6 JIC – 6 JIC
1
409
35-0060
Hydraulic Oil Filter Replacement
1
410
51-1050
Uni-Frame Battery Guide, Front
2
411
53-0398
Uni-Frame Filter Bracket
1
412
53-0399
Uni-Frame Battery Stop
2
413
53-0405
Uni-Frame Battery Guide Spacer, Front
1
414
71-0033
Infinity 2.0 Battery Pack, AGM 48 VDC
1
