Bartell Innovatech Terminator Infinity 2.0 - Page 22

P a g e | 22
OIPB-I01029-Infinity2.0_v1.2
Motor & Pump Breakdown
Item No.
Part Number
Description
Qty.
501
12-0018-10
Lock Washer, M10
2
502
12-0021-08
Nyloc Nut, M8
1
503
12-0021-10
Nyloc Nut, M10
2
504
12-0024
Hex Head Cap Screw, M10-1.5 x 30mm
2
505
12-0032-16
Hex Head Cap Screw, M8-1.25 x 16mm
3
506
12-0032-45
Hex Head Cap Screw, M8-1.25 x 40mm
1
507
12-0034-40
Hex Head Cap Screw, M10-1.5 x 40mm
2
508
12-0035-08
Flat Washer, M8
5
509
12-0035-10
Flat Washer, M10
6
510
24-0160
Infinity 2.0 Motor, 5.5HP
1
511
31-0281
Hydraulic Fitting, 90 deg 12 JIC – 10 SAE
1
512
31-0172
Hydraulic Fitting, 90 deg 6 JIC – 10 SAE
1
513
31-0286
Hydraulic Fitting, Straight 6 JIC – 10 SAE
1
514
31-0290
Infinity 2.0 Gear Pump, 6CC
1
515
53-0435
Infinity 2.0 Motor Mount
1
