Hood Arm Breakdown
Item No.
Part Number
Description
Qty.
701
11-0030
Flat Washer, #10
4
702
11-0034
Flat Washer, 5/16”
2
703
12-0021-05
Nyloc Nut, M5-0.8
1
704
12-0021-08
Nyloc Nut, M8-1.25
4
705
12-0032-16
Hex Head Cap Screw, M8-1.25 x 16mm
5
706
12-0041-12
Hex Head Cap Screw, M5-0.8 x 12mm
2
707
12-0044-20
Serrated Flange Cap Screw, M8-1.25
8
708
12-0050-16
Low Socket Cap Screw, M8-1.25 x 16mm
4
709
13-0387
12” Lanyard
1
710
53-0391
Uni-Frame Rear Side Support
2
711
53-0392
Uni-Frame Rear Cross Support
1
712
53-0393
Uni-Frame Hood Support
1
713
53-0394
Top Cover Mounting Bracket
1
714
53-0395
Uni-Frame Rear Support Bracket
2
715
96-0380
Infinity Top Cover Assembly
1
