Rear Panels & Support Breakdown
Item No.
Part Number
Description
Qty.
801
12-0043-16
Serrated Flange Cap Screw, M6-1.0 x 16mm
19
802
12-0044-20
Serrated Flange Cap Screw, M8-1.25 x 20mm
4
803
12-0045-20
Flat Head Phillips Screw, M6-1.0 x 20mm
4
804
51-1048
Uni-Frame Battery Guide, Rear
2
805
53-0373
Uni-Frame Back Panel
1
806
53-0391
Uni-Frame Rear Side Support
2
807
53-0392
Uni-Frame Rear Cross Support
1
808
53-0394
Top Cover Mounting Bracket
1
809
53-0395
Uni-Frame Rear Support Bracket
4
810
53-0406
Uni-Frame Battery Guide Spacer, Rear
2
811
53-0415
Uni-Frame Side Panel
2
