Rear Wheels Breakdown
Item No.
Part Number
Description
Qty.
901
12-0034-40
Hex Head Cap Screw, M10-1.5*40mm
4
902
11-0025
Nyloc Nut, 5/16”-18
2
903
11-0035
Flat Washer, 3/8”
4
904
12-0018-10
Lock Washer, M10”
12
905
12-0048-16
Hex Head Bolt, M10-1.5*16
8
906
11-0279-88
Hex Head Cap Screw, 1/4”-20 x 5 1/2”
2
907
11-0287
Socket Head Shoulder Screw, 3/8” x 3/8”, 5/16”-18
2
908
11-0353
Set Screw, #10-32 x 3/8”
1
909
13-0384
Rear Bumper
2
910
51-0513
Cable Clamp
1
911
53-0134
Brake Actuator
1
912
81-0091
Wheel Scraper Blade, 7.5” x 4.5”
2
913
96-0381
Infinity Left Wheel Assembly
1
914
96-0382
Infinity Right Wheel Assembly
1
915
12-0024
Hex Head Cap Screw, M10-1.5*30mm
4
