Bartell Innovatech Terminator Infinity 2.0 - Page 30

P a g e | 30
OIPB-I01029-Infinity2.0_v1.2
Infinity Controls Bracket (L) - Part # 96-0384
Item No.
Part Number
Description
Qty.
1301
12-0060
Socket Head Bolt, M8-1.25 x 60mm
3
1302
12-0049-70
Hex Head Bolt, M8-1.25 x 70mm
2
1303
12-0052
Socket Head Cap Screw, M5-0.8 x 60mm
4
1304
13-0023
Brake Cable
1
1305
13-0037
Brake Cable Clevis
1
1306
13-0050-1
Modified Brake Lever
1
1307
31-0094
Hydraulic Fitting, 90 deg 8 JIC – 8 SAE
1
1308
31-0163
Hydraulic Fitting, Flow Reducer 4 JIC – 8 SAE
2
1309
31-0233
Hydraulic Fitting, Straight 6 JIC – 8 SAE
2
1310
31-0287
Hydraulic Fitting, Long 90 deg 8 JIC – 8 SAE
1
1311
35-0057
Two-Section Valve
1
1312
53-0421
Infinity Mounting Bracket (L)
1
1313
53-0433
Infinity Brake Spacer
2
1314
53-0434
Infinity Handle Collar
1
1315
13-0275
Hose Clamp
2
1316
12-0018-08
Lock washer, M8
3
1317
32-0026
Pivot Box, Infinity Valve
2
