Infinity Right Wheel Assembly - Part # 96-0382
Item No.
Part Number
Description
Qty.
1401
11-0013
Hex Head Cap Screw, 1/2”-13 x 3”
2
1402
11-0028
Nyloc Nut, 1/2”-13
4
1403
11-0029
Nyloc Nut, 1/2”-20
5
1404
11-0228
Hex Head Cap Screw, 1/2”-13 x 5”
2
1405
11-0230
Flat Washer, 1/2”
5
1406
13-0021
Right Brake Caliper
1
1407
13-0022
Brake Mounting Bracket
1
1408
31-0053
Hydraulic Fitting, 90 deg 8 JIC – 10 SAE
2
1409
33-0003
Right Wheel Motor
1
1410
51-0491
Brake Spacer Standoff
2
1411
53-0208
Wheel and Tire Assembly
1
1412
70-0016
Wheel Hub with Brake Disc
1
