Bartell Innovatech Terminator Infinity 2.0 - Page 32

P a g e | 32
OIPB-I01029-Infinity2.0_v1.2
Infinity Left Wheel Assembly - Part # 96-0381
Item No.
Part Number
Description
Qty.
1501
11-0013
Hex Head Cap Screw, 1/2”-13 x 3”
2
1502
11-0028
Nyloc Nut, 1/2”-13
4
1503
11-0029
Nyloc Nut, 1/2”-20
5
1504
11-0228
Hex Head Cap Screw, 1/2”-13 x 5”
2
1505
11-0230
Flat Washer, 1/2”
5
1506
13-0020
Left Brake Caliper
1
1507
13-0022
Brake Mounting Bracket
1
1508
31-0053
Hydraulic Fitting, 90 deg 8 JIC – 10 SAE
2
1509
33-0002
Left Wheel Motor
1
1510
51-0491
Brake Spacer Standoff
2
1511
53-0208
Wheel and Tire Assembly
1
1512
70-0016
Wheel Hub with Brake Disc
1
